Description
Overview
Jabsco Impeller Neoprene 4568-0001 provides reliable marine cooling and water transfer performance in demanding environments. It uses Jabsco’s Profile K configuration with 12 flexible blades and a key-driven brass hub for a firm, positive fit. Argomarine references this model under part ID J53-508 for easy sourcing.
Features
- Genuine Jabsco flexible impeller made from durable neoprene
- Strong brass hub with key drive for accurate alignment
- 12-blade design that delivers smooth water flow and fast priming
- Resists wear in both seawater and freshwater systems
Specifications and Materials
| Impeller Type | Jabsco Profile K |
| Material | Neoprene rubber with brass insert |
| Outside Diameter | 57 mm (2-1/4″) |
| Depth (Width) | 32 mm (1-1/4″) |
| Shaft Diameter | 16 mm (5/8″) |
| Drive Type | Key drive |
| Number of Blades | 12 |
| Jabsco Part Number | 4568-0001 |
For detailed dimensions and selection guidance, refer to the official Jabsco impeller chart on xylem.com.
Compatibility and Fitment
This impeller fits pumps designed for the Profile K series using a 57 mm diameter, 32 mm width and 16 mm key-drive shaft. It replaces worn rotors in many Jabsco raw-water and transfer pumps. Before fitting, always compare key measurements with your existing impeller. Additionally, lubricate lightly with water-based grease to make installation smoother and protect the blades. Because correct alignment prevents premature wear, ensure the hub engages fully before sealing the cover.
Compliance and Safety
Use this impeller only for seawater or freshwater circulation. Avoid petroleum-based lubricants since they degrade neoprene. Before service, isolate power and close all seacocks to reduce spillage. After fitting, inspect the gasket and confirm screw torque evenly across the pump cover. If you notice vibration or noise, stop operation immediately and re-check alignment. Proper maintenance keeps the system efficient and prevents costly downtime.
Marine Applications
The Jabsco Impeller Neoprene 4568-0001 serves a variety of onboard systems including raw-water engine cooling, deck wash units and bilge transfer pumps. Because its flexible blades sustain constant contact with the cam housing, it maintains suction even at low speeds. Moreover, the neoprene material balances toughness with elasticity, ensuring long service life under continuous use. Therefore, it remains a trusted choice among professional marine technicians and OEM installers.
Why Choose Argomarine
Argomarine supplies genuine Jabsco components backed by verified technical data, so every product performs as expected. Our team checks each impeller before dispatch and provides local assistance for sizing and identification. Furthermore, we deliver fast shipping and dependable support for both trade and retail customers. Discover more options within the Water Pump & Timing Cover Accessories category.
